*CRTh-35
Sensitivity 1.3mm/m = 0.0764°
*CRTh-60 : Sensitivity 0.5mm/m = 0.0286°
| Product No. | Size | Vial Size | Scale Width | Hole Pitch | Hole Diameter | Weight | Quantity per carton |
|---|---|---|---|---|---|---|---|
| CRTh-25 | φ25x10mm | φ6x10mm | 6mm | 16mm | 2.7mm | 5g | 1 |
| CRTh-30 | φ30x10mm | φ6x13mm | 7mm | 20mm | 2.7mm | 7g | 1 |
| CRTh-35 | φ35x12mm | φ7x17mm | 8mm | 23mm | 2.7mm | 13g | 1 |
| CRTh-60 | φ60x14mm | φ8x25mm | 13mm | 40mm | 4.2mm | 47g | 1 |
Special Order Examples
The following option fees may be quoted separately.- Change liquid color to transparent
- Chamfering
- Change mounting hole diameter
