*CR-35
Sensitivity 0.5mm/m = 0.0286°
*CR-15,CR-20 : Sensitivity 1.3mm/m = 0.0764°
| Product No. | Size | Vial Size | Scale Width | Weight | Quantity per carton |
|---|---|---|---|---|---|
| CR-15 | φ15x10mm | φ5x10mm | 6mm | 2g | 1 |
| CR-20 | φ20x15mm | φ6x12mm | 6mm | 5.5g | 1 |
| CR-25 | φ25x15mm | φ8x15mm | 8mm | 8.5g | 1 |
| CR-30 | φ30x15mm | φ8x20mm | 11mm | 12.5g | 1 |
| CR-35 | φ35x15mm | φ8x25mm | 13mm | 16.5g | 1 |
Special Order Examples
The following option fees may be quoted separately.- Change liquid color to transparent
- Chamfering
- Change mounting hole diameter
